Michel Bergmann
  Charge de Recherches

INRIA  centre Bordeaux Sud-Ouest
  Team MC2
  Phone : +33 (0)5 40 00 69 54
  Fax     : +33 (0)5 40 00 21 17
  Mailto: Michel.Bergmann at inria.fr

 Institut de Mathematiques de Bordeaux


Mathematiques Appliquees de Bordeaux
  351 cours de la Liberation

33405 TALENCE cedex











Research interests  [more details]


Mathematical modelling - Reduced Order Models - Numerical Simulations - Optimization and control - Stability Analysis...

... Toward applications
(windtubine, UAVs, Boat Propellers, Fluid-Structures Interactions)




Mathematical modelling


Reduced Order Models
(ROM)



Numerical Simulations


  • Finite Element Method
    2D, Delaunay Triangulation
    [POF05] [POF06a] [POF06b]
  • Finite Volume, Multigrid Method
    2D,Cartesian Meshes
    with penalization
    [JCP09]
  • Finite Differences with projection methods
    3D, 2nd order, Cartesian Grids, Immersed Boundary, Level Set

    Development of the code NaSCar (see movies)
    [B&B2014]
    [CICP13][JCP11]

Optimization and Control

  • Dual adjoint methods / optimal control & robust control LQR
    Drag reduction
    [POF05] [NNFM07] [MI07] [JCP08]
  • DNS & POD + trust region (TRPOD)
    Drag Reduction
    [JCP08] [NNFM07]
  • Artificial neural networks, genetic algorithms, inverse methods
    Control and estimation of the ingnition point of forest fire
    [CNME08]

Sability Analysis

  • Reduced Order Models
    [JESA11]
  • Sedimentation of bodies

Some applications of NaSCar solver






Self-propelled swimmers
(Simualtions with Cartesian Meshes + Penalization + Level Set)



3D Fish like swimming of a real makerel fish
(Obtained from pictures with skeleton and optimal transport)


             3D jelly fish like swimming                                 3D Ray swimming

another 3D Ray Swimming.


aquarium.





Control of Self-propelled swimmers

Turbulent fish-like swimming.
Control of the tail amplitude to reach a desired swimming velocity.

Fish maneuvers.
Goal: large fish sould go towards the small fish
Control the swimming law of the large fish by adding adaptive curvature.





Fluid-structure Interactions: Elastic body

Wave power extraction with an elastic "water snake"
("strong" implicit coupling between fluid and elastic structure)


Inertial Sea Wave Energy Converters

The energy is converted thanks to a gyroscope inside the floater.




Windturbine


Wind turbine ("low precision").


Wind turbine ("high precision") with tip vortices.



Boat Propeller
(Thrust generation)

laminar.
turbulent (Smagorinsky-Lilly LES model).






Boat (interface air/water/boat)

Air-water interface is computed with Continuous Surface Force model





Sedimentation of bodies


2D sedimentation of a  cylinder (presence of instability at Re=30...)

3D pressure distribution on a falling disk in a tube.

Sedimenation of spheres with contacts modeled with Newtonian central forces



Some instabilities


Rayleigh Taylor with density ratio 3

Rayleigh Plateau (with curvature limitator to allow 2D isntability).




Drag minimization of the cylinder wake in laminar regime

Natural uncontrolled flow. Cd=1.40 [video 7.2Mo]


Flow generated with optimal parameters found by TRPOD method. Cd=0.99 [video 2.9Mo]





Workshop on POD [more details]


Thanks to all speakers, some slides presentations can be downloaded in pdf format here.

Others


Photos (restricted access)
